HBS-PH-36-36-H-132-PG

36" Light Duty Pipe Hanger Rooftop Support With 12 Gauge Channel H-132-PG with Top Support and Fixed Width & Height

H-Block Standard HBS-PH 36" light duty pipe hanger suppport comes with 6 bases, cross beams and 12 gauge channel 1-5/8" H-132.
The HBS-PH is specifically designed for supporting piping.
All rooftop support systems come pre-assembled for easy installation.
Compatible with most rooftop materials or other flat surfaces.
UV resistant
Dampens vibrations
High visibility safety corners coated with ANSI orange #2535.1-1998
Resistant to freeze and thaw (ASTM D1171 modified)
ASTM D575 medthod B-modified compression/deflection testing.
All hardware required for assembly is included
Does not include clevis hangers, only shown for your reference

Submittal Sheets_HBS Series with H-132 PG Request Quote

Material:

Base is 100% recycled rubber tires

Finish

Pre-galvanized ASTM 653 steel

Other Finishes Available

Hot dipped galvanized ASTM A-123
Zinc trivalen chromium ASTM B-633-85
Powder coated spr-green ASTM B-117
PVC coating 40ML thickness (available upon request only).

Technical Information

HBS-PH 36" Light Duty Pipe Hanger Support Series with H-132PG Top Support

Model No.	Height	Strut Width	Base Width	Base Length	No. of Bases	Weight (lbs)	Uniform Load Capacity (lbs)	Safety Factor
HBS-PH-36-36-H-132-PG	36" (914mm)	36" (914mm)	39 3/8" (1000mm)	36" (914mm)	6	62	974	2.0
HBS-PH-36-48-H-132-PG	36" (914mm)	48" (1219mm)	51 3/8" (1305mm)	36" (914mm)	6	64	731	2.0
HBS-PH-36-60-H-132-PG	36" (914mm)	60" (1524mm)	63 3/8" (1610mm)	36" (914mm)	6	66	588	2.0
HBS-PH-36-72-H-132-PG	36" (914mm)	72" (1829mm)	75 3/8" (1915mm)	36" (914mm)	6	68	487	2.0

*This load is only for the capacity of the components in this assembly with the pipe hangers located at a distance 1/4 from each end of the top channel. For any other loading scenario, please consult the appropriate engineer. Please consult Roofi ng manufacturer or engineer for roof load capacity.

Submittal Sheets_HBS Series with H-132 PG
