F-201
Square Washer
H-STRUT General Fittings are designed to fit with all H-STRUT 1-5/8" wide channels. All H-STRUT fittings are manufactured from 1/4" thick carbon steel, 1-5/8" wide, all holes are 9/16" diameter, spaced 1-7/8" on center and 13/16" from the end.
Sizes available:
- 1/4" - Wt. 18#/100 pcs.
- 5/16" - Wt. 18#/100 pcs.
- 3/8" - Wt. 18#/100 pcs.
- 1/2" - Wt. 17#/100 pcs.
- 5/8" - Wt. 16#/100 pcs.
- 3/4" - Wt. 15#/100 pcs.
- 7/8" - Wt. 14#/100 pcs.
Submittal Sheets_F-201
