E-501

Conduit Connector Plate

H-STRUT Conduit Connector Plates are UL Listed and are designed to fit all H-STRUT channels to make a surface raceway. Electrical Fittings are also designed to fit all H-STRUT channels. E-501-1/2 (for 1/2" conduit) E501-3/4 (for 3/4" conduit)
Wt. 28#/C

Submittal Sheets_E-501 Request Quote

Length

For 1/2" or 3/4" Conduit Connector Plate

Material

Channels, Closure Strips and Accessories are manufactured from the following materials:

  • Hot Rolled Steel Sheet - A-1011-04-SS
  • Cold Rolled Steel Sheet - ASTM A-1008
  • Stainless Steel-Type 304/316 - ASTM A-240

Finish

Channels, Closure Strips and Accessories are available in the following finishes:

  • Pre-Galvanized - ASTM A-653-G90
  • Hot Dipped Galvanized - ASTM A-123
  • Zinc Trivalent Chromium - ASTM B-633-85
  • Powder Coated Supr-Green - ASTM B-117
  • Plastic: Green, white, black Other finishes available upon request

E-501

H-STRUT: E501

UNISTRUT: P-2536

E-501-1/2

H-STRUT: E501-1/2

POWERSTRUT: PS-2560

B-LINE: B-447-1/2

E-501-3/4

H-STRUT: E501-3/4

POWERSTRUT: PS-2561

B-LINE: B-447A-3/4
