C-410

2 1/2" Height Open Wide Mouth Beam Clamp

H-STRUT Open Wide Mouth Beam Clamps are designed to secure all H-STRUT 1-5/8" wide channels, or threaded rod, to beams or supports for the purpose of running piping, conduit or tubing. All H-STRUT fittings are manufactured from 1/4" thick carbon steel or cast malleable iron. Please specify model, material and finish when ordering. Please contact us for any other clamps you may need.

Submittal Sheets_C-410 Request Quote

Material

Hot Rolled Steel Sheet - ASTM A-1101
Cold Rolled Steel Sheet - ASTM A-1008
Stainless Steel-Type 304/316
ASTM A-240
Malleable Cast Iron

Finish

Electro-Galvanized - ASTM B-633
Hot Dipped Galvanized - ASTM A-123
Zinc Trivalent Chromium - ASTM B-633-85
Powder Coated Supr-Green - ASTM B-117
PVC Coating - Available Upon Request

Model	A	B	C	D	Wt./100 Pcs.
C-410-1	1/4"-20	1/8"	3/8" x 1-1/2"	7/8"	67
C-410-2	5/16"-18	1/8"	3/8" x 1-1/2"	7/8”	67
C-410-3	3/8"-16	1/8"	3/8" x 1-1/2"	7/8”	67
C-410-4	3/8"-16	3/16"	1/2" x 1-1/2"	5/16”	100
C-410-5	1/2"-13	3/16"	1/2" x 1-1/2"	5/16”	100
C-410-6	1/2"-13	1/4"	1/2" x 1-1/2"	5/16”	100
C-410-7	5/8"-11	1/4"	1/2" x 1-1/2"	5/16”	130
C-410-8	5/8"-11	5/16"	5/8" x 1-1/2"	15/16”	160
C-410-9	3/4"-10	5/16”	5/8" x 1-1/2"	15/16”	160

Submittal Sheets_C-410

C-410-1

H-STRUT: C4101

UNISTRUT: P-1648-S

B-LINE: B-303

C-410-2

H-STRUT: C4102

UNISTRUT: P-1649-S

B-LINE: B-304

C-410-3

H-STRUT: C4103

UNISTRUT: P-1649-AS

B-LINE: B-305

C-410-4

H-STRUT: C4104

UNISTRUT: P-1650

POWERSTRUT: PS-858-3/8

B-LINE: B-306

C-410-5

H-STRUT: C4105

UNISTRUT: P-1650-AS

B-LINE: B-307

C-410-6

H-STRUT: C4106

UNISTRUT: P-1651-S

POWERSTRUT: PS-858-1/2

B-LINE: B-308

C-410-7

H-STRUT: C4107

UNISTRUT: P-1651-AS

B-LINE: B-309

C-410-8

H-STRUT: C4108

UNISTRUT: P-1652-S

POWERSTRUT: PS-858-5/8

SUPERSTRUT: U560-5/8

C-410-9

H-STRUT: C4109

UNISTRUT: P-1653-S
