H-STRUT Pipe Hold-Down Two-Hole Strut Straps are all manufactured to fit into the standard openings of 1-5/8" channel to support runs of piping where desired, to secure the pipe in place.

  • Pipe Hold-Down Two-Hole Strut Straps come in Electro-Galvanized (EZN) finish.
  • Safety Factor 3.0
  • Other finishes available upon request.
  • When ordering specify figure number and O.D. size.

Submittal Sheets_C-1108 Request Quote

Specifications

Pipe Size A B C D Std. Pkg. Wt./100 Pcs. Load Rating
1/2" 2-7/8" 1/8" 9/32" 7/16" 50 23 500
3/4" 3-1/16" 1/8" 9/32" 7/16" 50 26 500
1" 3-11/32" 1/8" 9/32" 7/16" 25 31 500
1-1/4" 3-11/16" 1/8" 9/32" 7/16" 25 35 500
1-1/2" 3-29/32" 1/8" 9/32" 7/16" 25 39 500
2" 5-21/32" 1/4" 13/32" 13/16" 25 94 1,000
2-1/2" 6-5/32" 1/4" 13/32" 13/16" 25 114 1,000
3" 6-25/32" 1/4" 13/32" 13/16" 25 133 1,000
3-1/2" 7-9/32" 1/4" 13/32" 13/16" 10 152 1,000
4" 7-25/32" 1/4" 13/32" 13/16" Bulk 176 1,000
5" 7-27/32" 1/4" 13/32" 13/16" Bulk 198 1,000
6" 9-29/32" 1/4" 13/32" 13/16" Bulk 225 1,000

Design Loads*

Nominal Pipe Size Slip Thru (lbs) Slip Along (lbs) Pullout (lbs)
1/2" 425 479 811
3/4" 184 405 850
1" 168 455 769
1-1/4" 402 401 830
1-1/2" 315 532 876
2" 553 1,728 2,133
2-1/2" 408 1,615 2,280
3" 900 1,494 2,295
3-1/2" 646 1,516 2,273
4" 834 1,463 2,324
5" 564 1,097 2,324
6" 494 899 2,250

*Safety Factor: 3.0
