B-605

H-STRUT General Fittings are designed to fit with all H-STRUT 1-5/8" wide channels. All H-STRUT fittings are manufactured from 1/4" thick carbon steel, 1-5/8" wide, all holes are 9/16" diameter, spaced 1-7/8" on center and 13/16" from the end.
Wt. 233#/C

Use with:

1-5/8" x 1-5/8" 12-ga. Channel – H-132
1-5/8" x 1-5/8" 14-ga. Channel – H-134

Submittal Sheets_B-605 Request Quote

Material

H-STRUT fittings are manufactured from the following material:

Hot Rolled Steel Sheet - ASTM A-1011
Cold Rolled Steel Sheet - ASTM A-1008
Stainless Steel-Type 304/316 - ASTM A-240
Aluminum Fitting - ASTM B-221

Finish

H-STRUT fittings are available in the following finishes:

Electro Galvanized - ASTM B-633
Hot Dipped Galvanized - ASTM A-123
Zinc Trivalent Chromium - ASTM B-633-85
Powder Coated Supr-Green - ASTM B-117
PVC Coating - Available Upon Request

Submittal Sheets_B-605

B-605

H-STRUT: B605

UNISTRUT: P-1377

POWERSTRUT: PS-616

B-LINE: B-172

SUPERSTRUT: A208
