B-602

3-Hole Slotted "U" Adjustable Support

H-STRUT General Fittings are designed to fit with all H-STRUT 1-5/8" wide channels. All H-STRUT fittings are manufactured from 1/4" thick carbon steel, 1-5/8" wide, all holes are 9/16" diameter, spaced 1-7/8" on center and 13/16" from the end.
Sizes available:

7-1/4" - Wt. 103#/100 pcs.
8-1/2" - Wt. 115#/100 pcs.
10-3/8" - Wt. 135#/100 pcs.

Submittal Sheets_B-602 Request Quote

Material

Hot Rolled Steel Sheet - ASTM A-1011
Cold Rolled Steel Sheet - ASTM A-1008
Stainless Steel-Type 304/316 - ASTM A-240
Aluminum Fitting - ASTM B-221

Finish

Electro Galvanized - ASTM B-633
Hot Dipped Galvanized - ASTM A-123
Zinc Trivalent Chromium - ASTM B-633-85
Powder Coated Supr-Green - ASTM B-117
PVC Coating - Available Upon Request

Submittal Sheets_B-602

B-602-1

H-STRUT: B6021

UNISTRUT: P-1048

POWERSTRUT: PS-687-A

B-LINE: B-333-1

B-602-2

H-STRUT: B6022

UNISTRUT: P-1049

POWERSTRUT: PS-687-B

B-LINE: B-333-2

B-602-3

H-STRUT: B6023

UNISTRUT: P-1050

POWERSTRUT: PS-687-C
